Custom lithium replacement solution specially designed for electric walkie pallet trucks & stackers (light-duty warehouse equipment).

Conventional lead-acid batteries fitted on Linde, Toyota and Baoli small warehouse trucks commonly suffer from fast capacity drop, frequent routine maintenance, short service life and acid leakage causing body corrosion. Based on original battery compartment size, electrical specs and vehicle control logic, we customize the 24V 315Ah LiFePO4 upgrade battery. It directly replaces the original 24V lead-acid pack with no truck modification needed, delivering maintenance-free, longer runtime and safer operation for daily light-load warehouse work.

Our technical team finishes full compatibility tests on vehicle control logic, communication protocol and battery cavity dimension. The lithium battery’s size, weight and wiring terminals match the original lead-acid unit 1:1. No rewiring, controller adjustment or counterweight modification is required; direct plug-and-play swap, operators keep original driving habits with zero adaptation period.

After conversion, customers eliminate regular lead-acid maintenance: water topping-up, acid mist cleaning and equalization charging. Lithium service life is 2–3 times longer than lead acid; no battery replacement needed within 5-year warranty, cutting overall running cost by 40%–60%. We tailor dimensions and parameters flexibly per clients’ actual vehicle and space demands.

Rated at 25.6V & 315Ah, the battery outputs steady continuous power. It maintains consistent performance during frequent short-distance hauling and medium-height stacking without obvious power fading seen on aged lead-acid batteries. High-rate discharge design enables instant response for startup, acceleration and lifting, lifting overall working efficiency by over 15% versus equivalent lead-acid alternatives.

Constructed with automotive-grade LiFePO4 cells with minimal thermal runaway risk. Cycle life ≥2500 cycles @80% DOD, 2–3× longer than traditional lead-acid batteries and stable performance guaranteed over 5 years’ regular use. 100% maintenance-free: No regular water filling, specific gravity testing, acid residue cleanup or equalizing charge. Save plenty of labor and accessory costs while avoiding truck corrosion from leaked electrolyte.

Built-in industrial intelligent BMS monitors single cell voltage, current and temperature in real time. More than 10 built-in protections include overcharge, overdischarge, overcurrent, short-circuit, overheat and low-temperature preheating to remove potential safety risks. Active cell balancing keeps uniform voltage across all cells to prevent premature pack degradation. Integrated adaptive thermal management enables low-temp preheat and high-temp heat dissipation automatically. All products pass ISO 9001, CE, RoHS, UN38.3, IEC, IAF certifications. Cells and finished packs pass strict puncture, extrusion and short-circuit tests, eligible for export to Europe, America, Southeast Asia, Africa and other global markets.

Overall dimension, weight and wiring interface fully match original lead-acid layout. Replace old battery directly without changing truck circuits, controllers or counterweights. Original vehicle stability, loading and braking features remain unchanged for small warehouse trucks. Compatible light-duty models: Linde pedestrian pallet truck series, Toyota hand stacker & walkie pallet series, Baoli small electric pallet/stacker series. Custom development available for special non-standard models.

Max charging current ≤100A; reach 90% SOC within 3 hours. Operators complete quick top-ups during rest breaks to support double or triple-shift non-stop working. Casual partial opportunity charging causes no damage to battery lifespan and improves equipment availability greatly. Energy efficiency exceeds 95%, around 25% higher than lead acid, cutting electricity expense by 20%–30% under identical workload.

Free of lead, cadmium and corrosive acid liquid; no acid mist or waste fluid pollution. Reliable operation from -20℃ to +55℃, retaining over 80% discharge efficiency even inside cold storage with limited performance loss.

Item	Detailed Parameter
Brand	PROLAKER
Model	24V 315Ah
Battery Type	LiFePO4 Lithium-ion Battery
Rated Voltage	25.6V
Rated Capacity	315Ah
Cycle Life	≥2500 cycles @ 80% DOD
Max Charging Current	≤100A
Compatible Equipment	Linde / Toyota / Baoli Light-Duty Walkie Pallet Trucks & Electric Stackers
Warranty	5 Years / 10,000 Working Hours (whichever comes first)
Global Certifications	ISO 9001, MSDS, RoHS, CE, UN38.3, IEC, IAF
