商品の詳細:
お支払配送条件:
|
| モデル: | エッシュ 80V 130A | 応用: | フォークリフト用リチウム電池 |
|---|---|---|---|
| 色: | 銀 | 材料: | 鋼鉄 |
| 全体の寸法: | 607×281.4×511.6mm | 最大出力電流: | 130a |
| 出力電力: | 13000w |
Product description
The ESCH forklift battery charger typically refers to an industrial charger used to replenish the energy in forklift batteries. These chargers are often designed for heavy-duty environments, aiming to ensure optimal performance, efficiency, and longevity of forklift batteries.
Key Features
Product Catalog
| Model | ESCH 80V 130A | ESCH 80V 150A | ESCH 80V 200A | |||
| Overall dimension | 607*281.4*511.6mm | |||||
| Maximum output current(A) | 130 | 150 | 200 | |||
| Output power(W) | 13000 | 15000 | 16000 | |||
| Input Power Supply | 380V土15% Four-wire | 380V土15% Four-wire | 380V土15% Four-wire | |||
| Maximum Output Voltage(VDC) | 100 | 100 | 100 | |||
| Compatible Battery Specification | 80V 400-600Ah lithium battery | |||||
| Maximum Efficiency | ≥94% | ≥94% | ≥94% | |||
| Output Voltage Regulation Accuracy | ±0.5% | ±0.5% | ±0.5% | |||
| Output Current Regulation Accuracy | ±1% | ±1% | ±1% | |||
| Operating Temperature | -40°C-50℃ | -40°C-50℃ | -40°C-50℃ | |||
| Vibration Resistance Grade | SAEJ1378 | |||||
| Cooling Method | Air Cooling | Air Cooling | Forced Air Cooling | |||
| Over Temperature Protection | 70℃ | 70℃ | 70℃ | |||
| Input Overvoltage Protection (VAC) | ＞530±10V | ＞530±10V | ＞530±10V | |||
| Input Undervoltage Protection (VAC) | ＜250±10V | ＜250±10V | ＜250±10V | |||
| Output Overvoltage Protection (VDC) | 105±5 | 105±5 | 105±5 | |||
| Output Overcurrent Protection (A) | >110% of Max Charging Current | |||||
| Output Short Circuit Protection | When output short-circuited, the charger shuts down automatically; it will self-recover after fault removal. | |||||
| Battery Reverse Polarity Protection | None | |||||
Product Display
